Features:

• The Pumps are portable and self priming.
• Fitted with Electric Motors in Monoblock Design.
• Sealed with double mechanical seal.
• Ideal for pumping contaminated liquids with fine solids, sandsor such other liquids.
• Nonclogging designs.
• Heavy duty bearing.Built in-in overload protection.
• Supplied with 5mtr.(1Mtr.)cable as standard

Types of Impeller:

• Semi-open impeller Cutting foreign particles and preventing clog by solid media.
• This impeller can generater apid rotating vortex to handle fluid mixed with long fiber. The majority of abrasive solids do not touch impeller to minimize impeller wear.

Float Switch:

• Excellent quality flot switch provides with epoxy resin sealed connector.

Industrial:

• Drainage of sewage from the building basements, hotel, industry, waste water from factories.
• Drainage of sewage from industrial process factories.
• Emptying for septic tanks,cesspits and sewage pump stations.
• Pumping surface and drainage water from garages and sprinkler systems.
• Swimining Pool Filtration.

Srandard Specification:

• Power Range: 1.0HPto5.0HP
• Supply: 225 Volts, 1phase, 50Hz AC supply, 415Volts, 3phase, 50Hz AC supply
• Speed: 2800 RPM
• Insulation: "B" Class
• Motor Degree of Protection: lp-54
• Operating Conditions: -Liquid Temperature upto 40°
                                          -Ambient Temperature upto 50°
                                          -Max. Startsper
                                          -Hour 30 at Regular Intervals
                                          -Continuous Duty
                                          -Max Depth 18.5M
